  • Demister Filter

    Clapboard:withoutClapboardFilterNumber:1MediumMaterial:StainlessSteelMeshFiltrationGrade:PreFilterType:PanelFilterTransportPackage:Cardbaord+WoodenBox


    Model NO.
    HWM
    • Specification
    492*238*46 619*492*46
    Trademark
    KOSAFILTER
    Origin
    China
    HS Code
    8421999090
    Production Capacity
    40000PCS/Year


    Product Description




    Application
    Suitable as pre-filter in ventilation systems of office buildings, conference rooms, hospitals, shopping malls, gymnasium, airports and other huge civil architecture as well as pre-filter in general factories of clean rooms.
    Advantages
    Aluminum frame will reduce the frequency of cleaning and maintenance.
    Multi-layer corrugated aluminum mesh, low initial pressure drop, high dust-holding capacity and long service life.
    Light in weight, compact in structure, easy to install.
    Can be washed repeatedly with compressed air or cleaning fluid.
    Good fireproof property, greatly reduce the risk of fire.
    Good heat dissipation property, extend the life of the fan motor.
    Meet EN779:2012.
    Material Instructions
    Media: Multi-layer corrugated metal mesh.
    Frame: Aluminum alloy or stainless steel.
    Structure Drawings

    Common Specifications
      ModelDimensionsRated Air Flow (m3/h)Face Velocity
    (m/s)    		Initial Pressure Drop (Pa)
    W×L×D (mm)
    HWM-20×10×2492×238×4610502.515
    HWM-20×16×2492×390×461720
    HWM-20×20×2492×492×462170
    HWM-24×24×2594×594×463170
    HWM-25×16×2619×390×462170
    HWM-25×20×2619×492×462740.
    KOSAFILTER makes various of other models' HWM filter not listed in above table. Please consult with us if you need.

    The Initial Pressure Drop and Rated Air Flow Performance Curve
