  • High Quality Custom Pleated Carboard Frame Pre Air Filter

    Clapboard:withoutClapboardFilterNumber:1MediumMaterial:NonwovenFabricEfficiency:G4FiltrationGrade:PreFilterType:PanelFilter


    Model NO.
    HPP
    • Media
    Non-Woven Fabrics with Pleated Mesh Supporte
    Frame
    Cardboard
    Temperature
    Maximum 90°c in Continuous Service.
    Pre Filter
    G4
    Transport Package
    Carton/Wooden Case
    Specification
    595x595x46mm
    Trademark
    KOSAFILTER
    Origin
    China
    HS Code
    8421999090
    Production Capacity
    5000PCS


    Product Description



    Application
    Suitable as pre-filter used to protect high-performance filters, and filtration of fresh air in clean room ventilation system and airport, subway, shopping malls and other places of public services.
    Advantages
    Filtration efficiency rating from G3 to M5, traps 40~60% of ≥5.0μm particles.
    Use special low-resistance and high-throughput non-woven fabrics as the filter material, with high dust-holding capacity.
    There are cardboard, galvanized steel sheet, stainless steel sheet, aluminum alloy or plastic frame.
    Meet EN779:2012.
    Material Instructions
    Media: Non-woven fabrics with pleated mesh supporter or metal pillar.
    Frame: Cardboard, galvanized steel sheet, stainless steel sheet, aluminum alloy or plastic.
    Temperature: Maximum 90°C in continuous service.
    Structure Drawings

    Common Specifications
     ModelDimensionsRated Air Flow (m3/h)Initial Pressure Drop (Pa)Media Area
    (m2)    		  Pitch
    (mm)
    W×H×D (mm)  StandardHigh Capacity  StandardHigh Capacity
    HPP-12×24×1290×595×23600120020630.4019
    HPP-20×14×1493×341×2355011000.39
    HPP-20×15×1493×366×2362512500.43
    HPP-20×16×1493×391×2365013000.45
    HPP-20×20×1493×493×2380016000.56
    HPP-20×24×1493×595×2395019000.65
    HPP-24×24×1595×595×23120024000.83
    HPP-25×14×1620×341×2370014000.48
    HPP-25×16×1620×391×2380016000.57
    HPP-25×20×1620×493×23100020000.71
    HPP-14×20×2341×493×46850170020700.7720
    HPP-20×12×2493×290×4670014000.70
    HPP-20×16×2493×391×4690018000.94
    HPP-20×18×2493×442×46105021001.01
    HPP-20×20×2493×493×46120024001.12
    HPP-24×12×2595×290×4685017000.79
    HPP-24×18×2595×442×46130026001.24
    HPP-24×20×2595×493×46140028001.36
    HPP-24×24×2595×595×46170034001.64
    HPP-25×16×2620×391×46120024001.18
    HPP-25×18×2620×442×46135027001.27
    HPP-25×20×2620×493×46150030001.42
    HPP-20×16×4493×391×96950190018681.4528
    HPP-20×20×4493×493×96120024001.73
    HPP-24×12×4595×290×9685017001.28
    HPP-24×18×4595×442×96130026001.91
    HPP-24×20×4595×493×96140028002.09
    HPP-24×24×4595×595×96170034002.55
    HPP-25×16×4620×391×96120024001.82
    HPP-25×20×4620×493×96150030002.18
    HPP-25×29×4620×721×96215043003.27.
    KOSAFILTER makes various of other models' HPP filter not listed in above table. Please consult with us if you need.

    The Initial Pressure Drop and Rated Air Flow Performance Curve
