  • Industrial Filtration Equipment HEPA Pleat Carbon Fiber Air Filter

    Clapboard:withoutClapboardMediumMaterial:ActivatedCarbonFrame:ABSPlasticTransportPackage:CartonTrademark:KOSAOrigin:Shanghai


    Model NO.
    HACV
    • HS Code
    8421999090


    Product Description


    You can find exquisite mini pleat activated caroal filters of different types in KOSA. We will provide the perfect mini pleat activated caroal filter to you at a relative low price.
    ModelDimensionsStructural StyleFrameMedia Area (m2)Rated Air Flow (m3/h)Initial Pressure Drop (Pa)
    W×H×D (mm)
    HACV1212-2VF287×287×292287 Header2V ABS2.180080
    HACV1220-2VF287×490×2923.81200
    HACV1224-2VF287×592×2924.71600
    HACV2012-3VF490×287×292490 Header3V ABS3.21100
    HACV2020-3VF490×490×2925.81900
    HACV2024-3VF490×592×2927.22400
    HACV2412-3VF592×287×292592 Header3V ABS3.21100
    HACV2420-3VF592×490×2925.81900
    HACV2424-3VF592×592×2927.22400
    HACV2412-4VF592×287×2924V ABS3.21600
    HACV2420-4VF592×490×2927.72500
    HACV2424-4VF592×592×2929.43200
    HACV2412-5VF592×287×292592 Header5V ABS5.21800
    HACV2420-5VF592×490×2929.53200
    HACV2424-5VF592×592×29211.73900
    HACV1212-2V305×305×292610 Box2V ABS2.7850
    HACV1224-2V305×610×2925.41700
    HACV2412-5V610×305×2925V ABS6.72100
    HACV2424-5V610×610×29213.54200

    KOSA makes various other models of HACV filter not listed the above table. Please consult with us if you need.


    Using carbon particles and ultrafine synthetic fibres composite material, effectively removing harmful substances in the air

    Larger filter area, reliable performance with high adsorption capacity and removal efficiency
    Light weight, easy installation and maintenance

    Frame is made of ABS, easy to dispose in accordance with environmental protection requirements

    Applied to central air conditioning and ventilation systems, to eliminate light concentrations of organic pollutants, sulfur dioxide, nitrogen dioxide, with the function of removing dust and gas contamination at the same time.
