  • Gel Seal HEPA Filters for Air Conditioning Diffusers Ceiling

    Clapboard:withoutClapboardMediumMaterial:FiberglassEfficiency:U15-U17FiltrationGrade:ULPAFilterType:PanelFilterMedia:Ultra-FineFiberglassPaper


    Model NO.
    HMG
    • Structure
    L-Type Side Gel Seal, Y-Type Top Gel Seal
    Frame
    Anodized Aluminum Alloy
    Separator
    Hot-Melt Glue
    Sealant
    Polyurethane
    Temperature
    Maximum 90ºC in Continuous Service
    Transport Package
    Carton and Wooden Case
    Trademark
    KOSAFILTER
    Origin
    Shanghai
    HS Code
    8421999090


    Product Description




    Advantages
    Filter efficiency ranges from H14 to U17.
    Adopt computer-controlled automatic production line for manufacturing, the crest height of folding filter material can be regulated steplessly between 18~96 mm, width will reach 1240mm at the widest.
    Use special ultra-fine fiberglass paper as the filter media, good stability of filtration efficiency.
    Double side retainers, protect the filter material, good strength.
    Light in weight, compact in structure.
    Each ULPA/HEPA filter is tested according to EN1822:2009.





    Material Instructions
    Structure: L-type side gel seal, Y-type top gel seal.
    Media: Ultra-fine fiberglass filter paper.
    Frame: Anodized aluminum alloy.
    Separator: Hot-melt glue.
    Sealant: Polyurethane.
    Temperature: Maximum 90°C in continuous service.

    Application
    Suitable for electronics, pharmaceutical industry, clean room, HEPA diffuser, laminar flow devices and the occasions require ultra-high cleanliness.

    Common Specifications

    Model    		DimensionsMedia Area
    (m2)    		Rated Air Flow
    (m3/h)    		Initial Pressure Drop
    (Pa)
    W×H×D (mm)
    HMG610/10-70L610×610×709.5800≤220
    HMG610/03-93L305×305×932.7250
    HMG610/05-93L305×610×935.9500
    HMG610/10-93L610×610×9313.01000
    HMG610/15-93L915×610×9320.01500
    HMG610/20-93L1220×610×9327.02000
    HMG610/03-104Y305×305×1043.4320≤250
    HMG610/05-104Y305×610×1046.8640
    HMG610/10-104Y610×610×10413.91280
    HMG610/15-104Y915×610×10420.91920
    HMG610/20-104Y1220×610×10428.02560

    KOSAFILTER makes various of other models' HMG filter which are not listed in above table. Please consult with us if you need.

    In case of specifications or structures changes, KOSA will provide up-to-date data on website: www.kosafilter.com.
