  • Elimated The Harmful Gasses-Activated Carbon Filter Box

    Clapboard:withoutClapboardFilterNumber:12MediumMaterial:FiberglassEfficiency:ActicatedCarbonGranulrFiltrationGrade:ActicatedCarbonGranulrType:VBankFilter


    Model NO.
    HACB
    • Media
    Columnar Activated Carbon Granule
    Frame
    Stainless Steel Sheet with Box
    Temperature
    Maximum 90ºC in Continuous Service
    Transport Package
    Carbon/Wooden Case
    Specification
    610x610x292mm-6V
    Trademark
    KOSAFILTER
    Origin
    China
    HS Code
    8421999090
    Production Capacity
    2000PCS


    Product Description


    HACB Activated Carbon Filter Box
    Application
    Suitable for industrial ventilation systems, eliminate the odor and harmful gases in air.
    A variety of special activated carbon materials can be provided according to the actual needs, effectively absorb gases such as VOC, acid gas, alkaline gas, formaldehyde, mercury vapor as well as radioactive gases.
    Advantages
    Activated carbon granule with a special chemical formula treatment.
    Reliable performance with high adsorption capacity and removal efficiency.
    Great versatility, convenient in installation and maintenance.
    Frame can be galvanized steel sheet, aluminum alloy or stainless steel sheet.
    Material Instructions
    Media: Columnar activated carbon granule with a special chemical formula treatment.
    Frame: Galvanized plate, stainless steel sheet with box structure.
    Temperature: Maximum 90ºC in continuous service
    Structure Drawings


    Common Specifications
      ModelDimensions
    W×H×D (mm)    		Removal Efficiency
    (%)    		Carbon Content /  Weight
    (kg)    		Pressure Drop (Pa) @ Air Flow (m3/h)
    Honeycomb Type Filled TypeHoneycomb Type
    Filled Type
    HACB-242412-4V610×610×29285~9514.5 / 2618 / 29180@3600230@3600
    HACB-241212-4V610×305×2927 / 138.5 / 14180@1800230@1800
    HACB-122412-2V305×610×2927 / 138.5 / 14180@1800230@1800
    HACB-121212-2V305×305×2923.5 / 6.54.2 / 7180@900230@900.
    KOSAFILTER makes various of other models' HACB filter not listed in above table. Please consult with us if you need.

    The Pressure Drop and Air Flow Performance Curve
    In case of specifications or structures changes, KOSA will provide up-to-date data on website: www.kosafilter.com.
