  • U15 Gel Seal Mini-Pleat HEPA Air Filter for HEPA Box

    Clapboard:withoutClapboardFilterNumber:1MediumMaterial:NonwovenFabricEfficiency:F6FiltrationGrade:MediumFilterType:PanelFilter


    Model NO.
    HMG
    • Media
    Non-Woven Fabrics with Pleated Mesh Supporter
    Frame
    Galvanized Plate
    Structure
    Single Header
    Temperature
    Maximum 90°c in Continuous Service
    Transport Package
    Carton/Wooden Case
    Specification
    290x595x46mm
    Trademark
    KOSAFILTER
    Origin
    China
    HS Code
    8421999090
    Production Capacity
    2500PCS


    Product Description


    Application
    Suitable for the electronics, bio-pharmaceutical, machinery, instrumentation, petrochemical and light industry as general air purification systems.
    Advantages
    Filtration efficiency rating from M5 to F9, traps 65~95% of ≥1.0μm particles.
    Use special low-resistance and high-throughput non-woven fabrics as the filter material, with high dust-holding capacity.
    Frame can be made of galvanized steel sheet, stainless steel sheet, aluminum alloy or ABS plastic.
    Meet EN779:2012.
    Material Instructions
    Media: Non-woven fabrics with pleated mesh supporter or metal pillar.
    Frame: Galvanized plate, aluminum, stainless steel plate or plastic.
    Structure: Box type, single header or double flanges type.
    Temperature: Maximum 90°C in continuous service.
    Structure Drawings
     Common Specifications
      ModelDimensions  No. of FoldsMedia Area (m2)Initial Pressure Drop (Pa) @ Air Flow (m3/h)
    W×H×D (mm)M5
    40~45%    		M6
    60~65%    		F7
    80~85%    		F8
    90~95%
    HPM-12×24×2290×595×4690.4640@25060@25070@250100@250
    HPM-24×24×2595×595×46170.940@50060@50070@500100@500
    HPM-12×24×3290×595×6990.740@40060@40070@400100@400
    HPM-24×24×3595×595×69171.440@79060@79070@790100@790
    HPM-12×24×4290×595×9090.940@50060@50070@500100@500
    HPM-24×24×4595×595×90171.840@100060@100070@1000100@1000
    HPM-12×24×6290×595×15091.540@85060@85070@850100@850
    HPM-24×24×6595×595×150173.040@170060@170070@1700100@1700
    HPM-12×24×12290×595×29293.040@170060@170070@1700100@1700
    HPM-24×24×12595×595×292176.040@340060@340070@3400100@3400.
    KOSAFILTER makes of various other models' HPM filter not listed in above table. Please consult with us if you need.
     The Initial Pressure Drop and Rated Air Flow Performance Curve
