  • Pre Washble Non-Woven Filter

    Clapboard:withoutClapboardFilterNumber:1MediumMaterial:NonwovenFabricEfficiency:F5FiltrationGrade:PreFilterType:PanelFilter


    Model NO.
    HPP
    • Transport Package
    Carton+Wooden Box
    Specification
    493*493*46
    Trademark
    KOSAFILTER
    Origin
    China
    HS Code
    8421999090
    Production Capacity
    100000psc/Year


    Product Description



     Common Specifications

    Model
    Dimensions
    Rated Air Flow (m3/h)
    Initial Pressure Drop (Pa)
    Media Area
    (m2)
    Pitch
    (mm)
    W×H×D (mm)
    Standard
    High Capacity
    Standard
    High Capacity
    HPP-12×24×1290×595×23600120020630.4019
    HPP-20×14×1493×341×2355011000.39
    HPP-20×15×1493×366×2362512500.43
    HPP-20×16×1493×391×2365013000.45
    HPP-20×20×1493×493×2380016000.56
    HPP-20×24×1493×595×2395019000.65
    HPP-24×24×1595×595×23120024000.83
    HPP-25×14×1620×341×2370014000.48
    HPP-25×16×1620×391×2380016000.57
    HPP-25×20×1620×493×23100020000.71
    HPP-14×20×2341×493×46850170020700.7720
    HPP-20×12×2493×290×4670014000.70
    HPP-20×16×2493×391×4690018000.94
    HPP-20×18×2493×442×46105021001.01
    HPP-20×20×2493×493×46120024001.12
    HPP-24×12×2595×290×4685017000.79
    HPP-24×18×2595×442×46130026001.24
    HPP-24×20×2595×493×46140028001.36
    HPP-24×24×2595×595×46170034001.64
    HPP-25×16×2620×391×46120024001.18
    HPP-25×18×2620×442×46135027001.27
    HPP-25×20×2620×493×46150030001.42
    HPP-20×16×4493×391×96950190018681.4528
    HPP-20×20×4493×493×96120024001.73
    HPP-24×12×4595×290×9685017001.28
    HPP-24×18×4595×442×96130026001.91
    HPP-24×20×4595×493×96140028002.09
    HPP-24×24×4595×595×96170034002.55
    HPP-25×16×4620×391×96120024001.82
    HPP-25×20×4620×493×96150030002.18
    HPP-25×29×4620×721×96215043003.27
    :.
    Advantages
    Filtration efficiency rating from G3 to M5, traps 40~60% of ≥5.0μm particles.
    Use special low-resistance and high-throughput non-woven fabrics as the filter material, with high dust-holding capacity.
    There are cardboard, galvanized steel sheet, stainless steel sheet, aluminum alloy or plastic frame.
    Meet EN779:2012.

    Material Instructions
    Media: Non-woven fabrics with pleated mesh supporter or metal pillar.
    Frame: Cardboard, galvanized steel sheet, stainless steel sheet, aluminum alloy or plastic.
    Temperature: Maximum 90°C in continuous service.

    Application
    Suitable as pre-filter used to protect high-performance filters, and filtration of fresh air in clean room ventilation system and airport, subway, shopping malls and other places of public services.

    Primary Filter: G3 to M5

    Structure Drawings


    The Initial Pressure Drop and Rated Air Flow Performance Curve

    In case of specifications or structures changes, KOSA will provide up-to-date data on website: www.kosafilter.com.
